Neoscenica Incasso

Neoscenica^® Incasso

Built-in lateral Bug-proof without barriers

Resistant, efficient against the bugs, with an essential design. Neoscenica® is suitable for any needs of installation and complete ANIMA21®, the revolutionary Anti-wind system Bettio’s patent.

NEOSCENICA® INCASSO. inherits the best features of the SCENICA® INCASSO series and brings many improvements and innovations that make it unique. It represents the ultimate expression of the evolution of door mosquito net: it is resistant, functional and aesthetically valuable. The profiles and plastics have been designed to offer an effective barrier against annoying bedbugs. Complete ANIMA21, the revolutionary windproof system patented Bettio, which guarantees the tightness and operation of the mosquito net even in case of strong wind or shock. NEOSCENICA® INCASSO has been designed to be easy and quick to assemble and to adapt to any installation need, even in the presence of non-bearing ceiling, thermal coat or in case of thresholds inclined up to 13° installments. It can be fixed in the compartment or on the frame either by screws or thanks to the use of the double-sided adhesive combination and push unit. It is available both single and double leaf and thanks to the central output of the network is always perfectly symmetrical. NEOSCENICA®INCASSO represents the new frontier of the Bettio's flyscreen for doors, combining aesthetics and functionality in a completely new product.

MOVEMENT:

Lateral sliding; Scenica®;

INSTALLATION:

Built-in;

COMMAND:

Spring operated;

TOTAL DIMENSIONS:

50 mm

WIND LOAD RESISTANCE WITH STANDARD MESH:

Class 6 with Anima21® (Bettio international patent);

AJUSTEMENTS:

In height: +13 mm

OPENING:

Doors;

Details

Realizable dimensions

Leaves	Mesh	Standard production	Minimum dimensions	Maximum dimensions
1 Leaf	Grey, Black	Up to 2500 mm width	285 x 680 mm	2500 x 3400 mm
2 Leaves	Grey, Black	From 2501 mm width	570 x 680 mm	5000 x 3400 mm
1 Leaf	Velum	Up to 2000 mm width	285 x 680mm	2000 x 3400 mm
2 Leaves	Velum	From 2001 mm width	570 x 680mm	4000 x 3400 mm

NEOSCENICA®INCASSO can be realized if the height is at least taller 7 centimetres than the width of each hinged door.
From 2001 mm swing base, the network will present a support at the top.

Aluminum Color

Ral 9010 Matt

Ral 9010 Gloss

Ral 1013 Matt

Ral 9001 Matt

Brushed Silver

Silver Painted

Ral 7016 Matt

Bronze Painted

Testa di Moro 2001 Matt

Ral 8017 Matt

Elox 2000 Matt

Ral 6005 Matt

Renolit Light

Ciliegio

Renolit Dark

Acacia

Optional

Handcrafted natural leather flexible handle, allowing removal of the handle bar when the handle is covered by the window or other obstruction.

Silver grey sliding profile.

Fiberglass mesh with the same characteristics as the standard grey mesh.
It gives elegance to the mosquito net itself

Evolution of the classic mesh, more resistant and performing. Protects from damage caused by sunlight thanks to a slight shade effect.

Arrange the brackets on the window before installation: installing the mosquito net on site will be even easier and faster. The predisposition kit for quick fastening on site, is supplied in packs for about 20 mosquito nets

In the world of built-in system, we try to respond to every need. This aluminium bracket allow to connect the fixture and the balcony, leaving among them the exactly predisposition for install of our 50 mm built-in systems. In this way it's possible to assemble all easily on product workshop, and then pose together and simultaneously fixture, flyscreen and balcony, with obvious advantages in terms of time. Available in packaging of 30 pieces. Dimensions: 131 x 64 mm.

3 sides built-in frame: setting up the buil-it for the insertion also for thi profile, is possible distance Scenica®Incasso from the fixture in the presence of drainers.

Versions

Choose this version if you can fix the flyscreen at the top of the compartment

Choose this version if you need to attach the mosquito net sideways. Pay attention in the double door leaf as in addition to the side fastening you will need to anchor the profile frontally.

Choose this version if you want to install the mosquito net inside a compartment, perfectly adherent to the perimeter walls but do not want to drill laterally. The fastening is frontal: the product is separated from the frame by about 5 mm and the protection from insects is guaranteed by the perimeter walls.
